Overview & Basic Info
Life
Semi-Permanent Bridge
Supply Ability
10000 Ton/Tons Per Year
Packaging & Delivery
Package Size
3042.00cm * 2134.00cm * 176.00cm
Packing
40' Standard HQ Containers / Naked
Product Description
| ZB200 Truss Press Limited Table |
| NO. |
Internal Force |
Not Reinforced Model |
Reinforced Model |
| SS | DS | TS | QS |
SSR | DSR | TSR | QSR |
| 200 |
Truss Moment (kN.m) |
1034.3 | 2027.2 | 2978.8 | 3930.3 |
2165.4 | 4244.2 | 6236.4 | 8228.6 |
| 200 |
Truss Shear (kN) |
222.1 | 435.3 | 639.6 | 843.9 |
222.1 | 435.3 | 639.6 | 843.9 |
| ZB200 Geometric Characteristics (Half Bridge) |
| Structure |
Model |
Chord Area (cm2) |
Section Properties (cm3) |
Inertia (cm4) |
| SS |
SS |
25.48 |
5437 |
580174 |
| SS |
SSR |
50.96 |
10875 |
1160348 |
| DS |
DS |
50.96 |
10875 |
1160348 |
Professional Service Flow
-
1
Professional advice and explicit explanation from our service representatives.
-
2
Close touch with excellent engineers to meet your exact requirements.
-
3
Detailed guidance on product usage and necessary maintenance services.
-
4
Thorough inspection of bridge products to solve any technical issues.
-
5
Online service platform tracking to ensure maximum customer satisfaction.
Frequently Asked Questions
What kind of manufacturer are you?
We are a specialized steel bailey bridge manufacturer in China with over 20 years of experience, holding ISO9001:2015 certification and serving global markets including Nigeria, Cambodia, Vietnam, and more.
Are you a factory or a trading company?
We are a factory equipped with six production lines and various machinery specifically for fabricating steel bridge parts and other steel structures.
What quality standards do your products meet?
Our products meet CMA, CNAS, and ISO9001 standards, as well as Grade I road requirements, American loading standard HS25, and British loading standard HA.
Where is the main loading port?
While we can ship from any port in China, our main export port is Shanghai Port.
What is the lifespan of the ZB200 Bailey Bridge?
The ZB200 model is designed as a semi-permanent bridge structure, providing high durability for highway and tractor bridge usage.
What is the annual production capacity?
Our facility has a production capacity of approximately 10,000 tons or 10,000 pieces per year.
